JDS Labs EL AMP

By: JDS Labs

Model: EL AMP

Sku: M9W7XD24Z2

PKR 60,799

& FREE Standard Delivery

Availability: In Stock In Stock

New

  • HEADPHONE AMPLIFIER
  • Frequency Response 20Hz-20kHz +/- 0.1dB
  • THD+N 1kHz, 150 Ω 0.0009%
  • IMD SMPTE 150 Ω 0.0005%
  • Noise, A-Weighted -108 dBu
  • Crosstalk 150 Ω -67 dB
  • Output Impedance 0.1 Ω
  • Channel Balance +/- 0.56 dB
  • Max Continuous Output, 600Ω 140 mW (9.4VRMS)
  • Max Continuous Output, 150Ω 505 mW
  • Max Continuous Output, 32Ω 1.1 W
  • Peak Output Power, 32Ω 1.5W
  • Headphone Output 6.35mm (1/4")
  • Analog Input RCA
  • Line-Output RCA
  • Dual Gain 1.0x and 4.7x
  • Thin Film Resistors 0.1% Tolerance
  • Volume Potentiometer TaperAlps 15A
Quantity:
  • Add to Wishlist
  • Add to Compare

SIMPLIFIED DESKTOP AUDIO

We designed the Element Line to simplify your desktop audio experience. EL Amp combines a powerful headphone amplifier with a comfortable knob, housed in a precision machined chassis. Enjoy seamless transitions between your powered speakers and headphones.

WHAT THE CRITICS ARE SAYING

"This amp offers a really terrific value. When the well detailed, ever so slightly warm EL DAC meets the clean, linear EL amp, it is just pure, musical goodness. I'm not sure what, if anything, wouldn't sound right as rain when connected to these two."

"More than enough to handle anything and everything I threw at it. It responded in spades. Not only is it powerful, it's absolutely clean."

SMART LOGIC

Microprocessor controlled relays completely eliminate turn on/off pops and thumps produced by lesser amps.

ULTRA HIGH POWER

With 30V rails and peak output in excess of 1.5W, EL Amp drives all headphones on the market to extraordinary levels, from balanced armatures to planar magnetics.

REFERENCE GRADE SOUND

EL Amp exceeds TPD criteria, outmatching our baseline for audible perfection.

LOW OUTPUT IMPEDANCE

EL Amp's extremely low output impedance ensures transparent frequency response for all headphone loads.

DUAL GAIN

Low gain of 1.0x is well suited to driving efficient IEMs, while High gain easily powers demanding full size sets.

AUTO LINE OUTPUT

Automatic Line-Output allows you to toggle between headphones and powered speakers at the push of a button.

In the Box

  • JDS Labs EL AMP
  • 16VAC Power Adapter
